| 3-wire AC line input (117V, 60 Hz typical) with power-on indicator. Both Models are available in 220-240VAC@50Hz |
| Fixed DC output |
+5V@1.0A, ripple <5mV. |
| Variable DC output |
+1.3 V to +15V@0.5A, ripple <5mV. |
| Variable DC output |
-1.3V to -15V @ 0.5A, ripple <5mV. |
| Frequency Range |
0.1 Hz to 100 kHz in six ranges. |
| Output voltage |
0 to ±10V (20Vp-p). |
| Output Impedance |
600 ohms (except TTL). |
| Output current |
10mA maximum, short circuit protected. |
| Output waveforms |
sine, square, triangle, TTL. |
| Sine wave |
distortion <3% (10Hz to 100kHz). |
| TTL pulse |
rise and fall time <25 nS. drive to 10 TTL loads |
| Square wave |
rise and fall time <1.5µS |
| |
| 8 LED's, active high, 1.4 volt (nominal) threshold, inputs protected to ±20 volts. |
| |
|
| Two
pushbutton-operated, open-collector output pulsers, each with one
normally-open, one normally closed output. Each output can sink up to
250 mA. |
| |
|
| One 1 K ohm, one 10 K ohm, all leads available and uncommitted. |
| |
|
| |
|
|
| Two BNC connectors, pin available and uncommitted, shell connected to ground. |
| Two
SPDT slide switches, all leads available and uncommitted. 8-pole DIP
switch: one side of all eight switches connected and switchable to +5V
or ground, other side of all eight switches separate, available, and
uncommitted. |
|
| |
|
|
| |
| 0.25W, 8 ohms |
|
| |
|
|
| |
| Three
UBS-100 sockets with 840 tie-points each for a total of 2520
uncommitted tie-points. Two QT-59B Bus strips internally connected to
power and ground. Fifty tie-points each for +5V, +V,=15 V and ground. |
|
| |
|
|
| |
| High impact molded case. |
|
| |
|
|
| |
| Weight |
7 lbs, 13 oz. |
|
| Overall Dimensions |
with case: 14" H x 19" W x 7" D |
|
| Part Number |
104-5031 |
|
| |
|
|
| |
|
|
|
