MollerTargetMessenger Class Reference

#include <MollerTargetMessenger.hh>

Collaboration diagram for MollerTargetMessenger:

Public Member Functions
	MollerTargetMessenger (MollerTarget *)
	~MollerTargetMessenger ()
void	SetNewValue (G4UIcommand *, G4String)
Private Attributes
MollerTarget *	myTarget
G4UIdirectory *	TargetDir
G4UIcmdWithAString *	TargMatCmd
G4UIcmdWithAString *	TargCellMatCmd
G4UIcmdWithADoubleAndUnit *	TargZPosCmd
G4UIcmdWithADoubleAndUnit *	TargLengthCmd

Detailed Description

Definition at line 49 of file MollerTargetMessenger.hh.

Constructor & Destructor Documentation

MollerTargetMessenger::MollerTargetMessenger ( MollerTarget * myTar )

Definition at line 18 of file MollerTargetMessenger.cc.

References TargCellMatCmd, TargetDir, TargLengthCmd, TargMatCmd, and TargZPosCmd.

Referenced by MollerTarget::MollerTarget().

00019 :myTarget(myTar)
00020 {
00021   TargetDir = new G4UIdirectory("/moller/target/");
00022   TargetDir -> SetGuidance("target control.");
00023
00024   TargZPosCmd =  new G4UIcmdWithADoubleAndUnit("/moller/target/setCenterPositionInZ",this);
00025   TargZPosCmd->SetGuidance("Set the Z position of the target center");
00026   TargZPosCmd->SetParameterName("Size",true);
00027   //TargZPosCmd->SetRange("Size>=0.");
00028   TargZPosCmd->SetUnitCategory("Length");
00029   TargZPosCmd->AvailableForStates(G4State_PreInit,G4State_Idle);
00030
00031   TargMatCmd = new G4UIcmdWithAString("/moller/target/setTargetMaterial",this);
00032   TargMatCmd->SetGuidance("Select Material of the Target.");
00033   TargMatCmd->SetParameterName("choice",false);
00034   TargMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);
00035
00036   TargCellMatCmd = new G4UIcmdWithAString("/moller/target/setTargetCellMaterial",this);
00037   TargCellMatCmd->SetGuidance("Select Material of the Target Cell.");
00038   TargCellMatCmd->SetParameterName("choice",false);
00039   TargCellMatCmd->AvailableForStates(G4State_PreInit,G4State_Idle);
00040
00041   TargLengthCmd = new G4UIcmdWithADoubleAndUnit("/moller/target/setTargetLength",this);
00042   TargLengthCmd->SetGuidance("Set the Target Length.");
00043   TargLengthCmd->SetParameterName("fTargetLength",true, true);
00044   TargLengthCmd->SetDefaultValue(150.);
00045   TargLengthCmd->SetUnitCategory("Length");
00046   TargLengthCmd->SetDefaultUnit("cm");
00047   TargLengthCmd->AvailableForStates(G4State_PreInit,G4State_Idle);
00048 }

Here is the caller graph for this function:

MollerTargetMessenger::~MollerTargetMessenger ( )

Definition at line 52 of file MollerTargetMessenger.cc.

References TargCellMatCmd, TargetDir, TargMatCmd, and TargZPosCmd.

00053 {
00054   delete TargZPosCmd;
00055   delete TargMatCmd;
00056   delete TargCellMatCmd;
00057   delete TargetDir;
00058 }

Member Function Documentation

void MollerTargetMessenger::SetNewValue	(	G4UIcommand *	command,
		G4String	newValue
	)

Definition at line 62 of file MollerTargetMessenger.cc.

References myTarget, MollerTarget::SetTargetCellMaterial(), MollerTarget::SetTargetCenterPositionInZ(), MollerTarget::SetTargetLength(), MollerTarget::SetTargetMaterial(), TargCellMatCmd, TargLengthCmd, TargMatCmd, and TargZPosCmd.

00063 {
00064   G4cout << "#### Calling MollerTargetMessenger::SetNewValue() " << newValue << G4endl;
00065
00066   if( command == TargZPosCmd )
00067    {
00068      G4cout << "#### Messenger: Setting Target Z position to " << newValue << G4endl;
00069      myTarget->SetTargetCenterPositionInZ(TargZPosCmd->GetNewDoubleValue(newValue));
00070    }
00071
00072   if( command == TargMatCmd )
00073   {
00074       G4cout << "#### Messenger: Setting Target Material to " << newValue << G4endl;
00075       myTarget->SetTargetMaterial(newValue);
00076   }
00077
00078
00079   if( command == TargCellMatCmd )
00080   {
00081      G4cout << "#### Messenger: Setting Target Cell Material to " << newValue << G4endl;
00082      myTarget->SetTargetCellMaterial(newValue);
00083   }
00084
00085   if (command == TargLengthCmd)
00086     {
00087       G4cout << "#### Messenger: Setting Target Length to " << newValue << G4endl;
00088       myTarget->SetTargetLength(TargLengthCmd->GetNewDoubleValue(newValue)); }
00089
00090   G4cout << "#### Leaving MollerTargetMessenger::SetNewValue() " << newValue << G4endl;
00091 }
