MollerAnalysis Class Reference

#include <MollerAnalysis.hh>

Inheritance diagram for MollerAnalysis:
Inheritance graph
[legend]
Collaboration diagram for MollerAnalysis:
Collaboration graph
[legend]

Public Member Functions

 MollerAnalysis ()
 MollerAnalysis (MollerDetectorConstruction *)
 MollerAnalysis (const MollerAnalysis &right)
const MollerAnalysis & operator= (const MollerAnalysis &right)
 ~MollerAnalysis ()
void BeginOfRunAction (const G4Run *)
void EndOfRunAction (const G4Run *)
void BeginOfEventAction (const G4Event *)
void EndOfEventAction (const G4Event *)
void UserSteppingAction (const G4Step *)
void SetRootFileName (const G4String &)
void SetMomentum0 (G4double E0, G4double px, G4double py, G4double pz)
void SetMomentum1 (G4double E1, G4double px, G4double py, G4double pz)
void SetMomentum2 (G4double E2, G4double px, G4double py, G4double pz)
void SetDiffXS (G4double diffXS_in)
void SetTotXS (G4double totXS_in)
void SetRate (G4double rate_in)
void SetProcess (G4int i)
void AddData (MollerDetectorHit *aHit)

Private Attributes

MollerDetectorConstruction * myDetector
G4int NUM_DETS
MollerAnalysisMessenger * analysisMessenger
G4String rootfileName
G4int ev_num
G4int index
G4int partType
G4int splitProcess
G4int creatorProcess
TNtuple * ntup
Float_t fntup [39]
std::vector< G4int > hitsCollID
G4int verboseLevel
G4double generator
G4double event
G4double kineE0
G4double kineE1
G4double kineE2
G4double px0
G4double py0
G4double pz0
G4double px1
G4double py1
G4double pz1
G4double px2
G4double py2
G4double pz2
G4double theta0
G4double theta1
G4double theta2
G4double x0
G4double y0
G4double z0
G4double rate
G4double totXS
G4double diffXS

Static Private Attributes

static const G4bool doDIPS = 0
static const G4bool doCOLS = 0
static const G4bool doQUADS = 0

Detailed Description

Definition at line 41 of file MollerAnalysis.hh.

Constructor & Destructor Documentation

MollerAnalysis::MollerAnalysis (  )

Definition at line 42 of file MollerAnalysis.cc.

References analysisMessenger, creatorProcess, ev_num, index, kineE0, kineE1, kineE2, partType, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, splitProcess, theta0, theta1, theta2, verboseLevel, x0, y0, and z0.

00043 {
00044   if (gSystem) gSystem->ProcessEvents();
00045
00046   ev_num=0;
00047   partType=-1;
00048   splitProcess=-1;
00049   creatorProcess=-1;
00050   index=-1;
00051
00052   //  for (int i=0; i<NUM_DETS; i++) {
00053   //    hitsCollID[i] = -1;
00054   //  }
00055
00056   verboseLevel=0;
00057
00058   kineE0=0;  kineE1=0;  kineE2=0;
00059
00060   px0=0;  py0=0;  pz0=0;
00061   px1=0;  py1=0;  pz1=0;
00062   px2=0;  py2=0;  pz2=0;
00063
00064   theta0=0;  theta1=0;  theta2=0;
00065
00066   x0=0;  y0=0;  z0=0;
00067
00068   analysisMessenger = new MollerAnalysisMessenger(this);
00069   //G4cout << "Root file name is "<<rootfileName << G4endl;
00070 }

MollerAnalysis::MollerAnalysis ( MollerDetectorConstruction *  detector  )

Definition at line 71 of file MollerAnalysis.cc.

References analysisMessenger, creatorProcess, ev_num, MollerDetectorConstruction::getNumColl(), index, kineE0, kineE1, kineE2, myDetector, NUM_DETS, partType, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, splitProcess, theta0, theta1, theta2, verboseLevel, x0, y0, and z0.

00072 :myDetector(detector)
00073 {
00074   if (gSystem) gSystem->ProcessEvents();
00075
00076   G4int NUM_COLS = myDetector->getNumColl();
00077
00078   NUM_DETS = NUM_COLS;
00079   G4cout<<G4endl<<G4endl<<"NUM_COLS = "<<NUM_COLS<<G4endl<<G4endl;
00080
00081   ev_num=0;
00082   partType=-1;
00083   splitProcess=-1;
00084   creatorProcess=-1;
00085   index=-1;
00086
00087   //  for (int i=0; i<NUM_DETS; i++) {
00088   //    hitsCollID[i] = -1;
00089   //  }
00090
00091   verboseLevel=0;
00092
00093   kineE0=0;  kineE1=0;  kineE2=0;
00094
00095   px0=0;  py0=0;  pz0=0;
00096   px1=0;  py1=0;  pz1=0;
00097   px2=0;  py2=0;  pz2=0;
00098
00099   theta0=0;  theta1=0;  theta2=0;
00100
00101   x0=0;  y0=0;  z0=0;
00102
00103   analysisMessenger = new MollerAnalysisMessenger(this);
00104   //G4cout << "Root file name is "<<rootfileName << G4endl;
00105 }

Here is the call graph for this function:

MollerAnalysis::MollerAnalysis ( const MollerAnalysis &  right  )

Definition at line 107 of file MollerAnalysis.cc.

References creatorProcess, ev_num, index, kineE0, kineE1, kineE2, partType, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, splitProcess, theta0, theta1, theta2, verboseLevel, x0, y0, and z0.

00108   : RootAnalysis()
00109 {
00110   if (gSystem) gSystem->ProcessEvents();
00111
00112   ev_num=right.ev_num;
00113   partType=right.partType;
00114   splitProcess=right.splitProcess;
00115   creatorProcess=right.creatorProcess;
00116   index=right.index;
00117
00118
00119   //  for (int i=0; i<NUM_DETS; i++) {
00120   //    hitsCollID[i]=right.hitsCollID[i];
00121   //  }
00122
00123   verboseLevel=right.verboseLevel;
00124
00125   kineE0=right.kineE0;
00126   kineE1=right.kineE1;
00127   kineE2=right.kineE2;
00128
00129   px0=right.px0;
00130   py0=right.py0;
00131   pz0=right.pz0;
00132
00133   px1=right.px1;
00134   py1=right.py1;
00135   pz1=right.pz1;
00136
00137   px2=right.px2;
00138   py2=right.py2;
00139   pz2=right.pz2;
00140
00141   theta0=right.theta0;
00142   theta1=right.theta1;
00143   theta2=right.theta2;
00144
00145   x0=right.x0;
00146   y0=right.y0;
00147   z0=right.z0;
00148
00149 }

MollerAnalysis::~MollerAnalysis (  )

Definition at line 195 of file MollerAnalysis.cc.

References analysisMessenger.

00196 {
00197   delete analysisMessenger;
00198 }

Member Function Documentation

void MollerAnalysis::AddData ( MollerDetectorHit *  aHit  )  [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 102 of file MollerAnalysis.hh.

References creatorProcess, diffXS, ev_num, event, fntup, MollerDetectorHit::GetIon(), MollerDetectorHit::GetKineticEnergy(), MollerDetectorHit::GetMomentum(), MollerDetectorHit::GetTrackID(), MollerDetectorHit::GetType(), MollerDetectorHit::GetVertexPos(), MollerDetectorHit::GetVolume(), MollerDetectorHit::GetWorldPos(), index, kineE0, kineE1, kineE2, ntup, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, rate, splitProcess, theta0, theta1, theta2, and totXS.

Referenced by EndOfEventAction().

00102                                        {
00103
00104   fntup[0] = aHit->GetIon();
00105   fntup[1] = aHit->GetWorldPos().x();
00106   fntup[2] = aHit->GetWorldPos().y();
00107   fntup[3] = aHit->GetWorldPos().z();
00108   //fntup[4] = (Float_t)x0;
00109   //fntup[5] = (Float_t)y0;
00110   //fntup[6] = (Float_t)z0;
00111   fntup[4] = aHit->GetVertexPos().x();
00112   fntup[5] = aHit->GetVertexPos().y();
00113   fntup[6] = aHit->GetVertexPos().z();
00114   fntup[7] = aHit->GetKineticEnergy();
00115   fntup[8] = aHit->GetMomentum().x();
00116   fntup[9] = aHit->GetMomentum().y();
00117   fntup[10] = aHit->GetMomentum().z();
00118
00119   fntup[11] = (Float_t)kineE0;
00120   fntup[12] = (Float_t)px0;
00121   fntup[13] = (Float_t)py0;
00122   fntup[14] = (Float_t)pz0;
00123   fntup[15] = (Float_t)kineE1;
00124   fntup[16] = (Float_t)px1;
00125   fntup[17] = (Float_t)py1;
00126   fntup[18] = (Float_t)pz1;
00127
00128   fntup[19] = (Float_t)kineE2;
00129   fntup[20] = (Float_t)px2;
00130   fntup[21] = (Float_t)py2;
00131   fntup[22] = (Float_t)pz2;
00132
00133   fntup[23] = aHit->GetType();
00134   fntup[24] = aHit->GetVolume();
00135   fntup[25] = (Float_t)theta0;
00136   fntup[26] = (Float_t)theta1;
00137   fntup[27] = (Float_t)theta2;
00138   fntup[28] = (Float_t)ev_num;
00139   fntup[29] = (Float_t)splitProcess;
00140   fntup[30] = (Float_t)event;
00141   fntup[31] = (Float_t)creatorProcess;
00142
00143   if (!index&&
00144       (aHit->GetIon()||splitProcess==0)&&
00145       kineE0>0&&
00146       aHit->GetType()==0
00147       ) {
00148
00149     if (aHit->GetIon()) {
00150       fntup[32] = 2;
00151       fntup[33] = kineE2;
00152       fntup[34] = theta2;
00153     }
00154     else {
00155       fntup[32] = 1;
00156       fntup[33] = kineE1;
00157       fntup[34] = theta1;
00158     }
00159   }
00160   else if (aHit->GetTrackID()==1){
00161     fntup[32] = 1;
00162     fntup[33] = kineE1;
00163     fntup[34] = theta1;
00164   }
00165   else if (aHit->GetTrackID()==2){
00166     fntup[32] = 2;
00167     fntup[33] = kineE2;
00168     fntup[34] = theta2;
00169   }
00170   else {
00171     fntup[32] = 0;
00172     fntup[33] = 0;
00173     fntup[34] = 0;
00174   }
00175
00176   fntup[35] = aHit->GetTrackID();
00177
00178   fntup[36] = diffXS;
00179   fntup[37] = totXS;
00180   fntup[38] = rate;
00181
00182   ntup->Fill(fntup);
00183 }

Here is the call graph for this function:

Here is the caller graph for this function:

void MollerAnalysis::BeginOfEventAction ( const G4Event *   )  [virtual]

Reimplemented from RootAnalysis.

Definition at line 256 of file MollerAnalysis.cc.

References ev_num, gRootAnalysis, hitsCollID, NUM_DETS, and RootAnalysis::SetProcess().

00257 {
00258   ev_num++;
00259   if (gSystem) gSystem->ProcessEvents();
00260
00261   G4SDManager * SDman = G4SDManager::GetSDMpointer();
00262
00263   /*  if(hitsCollID[0]<0 || hitsCollID[1]<0 ||
00264      hitsCollID[2]<0 || hitsCollID[3]<0 ||
00265      hitsCollID[4]<0 || hitsCollID[5]<0 ||
00266      hitsCollID[6]<0 || hitsCollID[7]<0 ||
00267      hitsCollID[8]<0 || hitsCollID[9]<0 ||
00268      hitsCollID[10]<0 || hitsCollID[11]<0 ||
00269      hitsCollID[12]<0 || hitsCollID[13]<0 ||
00270      hitsCollID[14]<0 || hitsCollID[15]<0 || hitsCollID[16]<0
00271      )
00272   */
00273
00274   if((int) hitsCollID.size()==0)
00275     {
00276       G4cout<<G4endl<<G4endl<<"Setting hitsCollID"<<G4endl<<G4endl;
00277
00278       for (int i=0; i<NUM_DETS; i++) {
00279   G4String colNam = "detector";
00280   colNam+=G4UIcommand::ConvertToString(i+1);
00281   colNam+="/hitsColl";
00282
00283   G4cout << colNam << G4endl;
00284
00285   hitsCollID.push_back (SDman->GetCollectionID(colNam));
00286       }
00287
00288       G4cout<<G4endl<<"Finished setting hitsCollID"<<G4endl<<G4endl;
00289
00290     }
00291
00292
00293   gRootAnalysis->SetProcess(1);
00294   /* These are you lines Dustin! Only these three lines. */
00295   //gRootAnalysis->SetMomentum0();
00296   //gRootAnalysis->SetMomentum1();
00297   //gRootAnalysis->SetMomentum2();
00298   /*                 ****************                    */
00299 }

Here is the call graph for this function:

void MollerAnalysis::BeginOfRunAction ( const G4Run *   )  [virtual]

Reimplemented from RootAnalysis.

Definition at line 205 of file MollerAnalysis.cc.

References RootAnalysis::hfile, ntup, and rootfileName.

00206 {
00207   if (gSystem) gSystem->ProcessEvents();
00208
00209   G4cout << "Run Action has been entered\n" << G4endl;
00210
00211   G4cout << "Root file name is "<<rootfileName << G4endl;
00212
00213
00214   // This works:
00215   //G4String filenamechar=("~/scratch/ROOTfiles/"+rootfileName+".root");
00216   G4String filenamechar=(rootfileName+".root");
00217
00218   // This works:
00219   /*
00220   G4String filenamechar;
00221   filenamechar="~/scratch/ROOTfiles/";
00222   filenamechar += rootfileName;
00223   filenamechar += ".root";
00224   G4cout<<filenamechar<<G4endl;
00225   */
00226
00227   //char filenamechar[200];
00228   /*
00229   time_t rawtime;
00230   tm * ptm;
00231   time ( &rawtime );
00232   ptm = gmtime ( &rawtime );
00233   snprintf(filenamechar,200,"~/scratch/ROOTfiles/coll_test0_%02i%02i%02i_%02i%02i%02i.root",
00234        ptm->tm_year-100,ptm->tm_mon+1,ptm->tm_mday,(ptm->tm_hour+19)%24,ptm->tm_min,ptm->tm_sec);
00235   //  snprintf(filenamechar,200,"~/scratch/ROOTfiles/moller_%02i%02i%02i_%02i%02i%02i.root",
00236   //     ptm->tm_year-100,ptm->tm_mon+1,ptm->tm_mday,(ptm->tm_hour+19)%24,ptm->tm_min,ptm->tm_sec);
00237   printf(filenamechar);
00238   */
00239   //snprintf(filenamechar,200,"~/scratch/ROOTfiles/%s.root",rootfileName);
00240
00241   hfile = new TFile(filenamechar,"RECREATE","Root/G4 analysis");
00242   //hfile = new TFile(rootfileName,"RECREATE","Root/G4 analysis");
00243
00244
00245   string myntuple_string;
00246   myntuple_string="ion:x:y:z:x0:y0:z0:kineE:px:py:pz:kineE0:px0:py0:pz0:kineE1:px1:py1:pz1:kineE2:px2:py2:pz2:type:volume:theta0:theta1:theta2:ev_num:process:event:creator:hit:kineE_org:theta_org:track:diffXS:totXS:rate";
00247
00248   char *string_ntup = new char[myntuple_string.length()+1];
00249   strncpy (string_ntup,myntuple_string.c_str(),myntuple_string.length()+1);
00250
00251   ntup = new TNtuple("geant","G4 Results",(char *)string_ntup);
00252
00253   G4cout << "Run Action has been completed\n" << G4endl;
00254 }

void MollerAnalysis::EndOfEventAction ( const G4Event *  anEvent  )  [virtual]

Reimplemented from RootAnalysis.

Definition at line 483 of file MollerAnalysis.cc.

References AddData(), MollerDetectorHit::GetTrackID(), MollerDetectorHit::GetType(), gRootAnalysis, hitsCollID, NUM_DETS, RootAnalysis::SetMomentum0(), RootAnalysis::SetMomentum1(), RootAnalysis::SetMomentum2(), and RootAnalysis::SetProcess().

00484 {
00485
00486   if (gSystem) gSystem->ProcessEvents();
00487
00488   G4HCofThisEvent * HCE = anEvent->GetHCofThisEvent();
00489
00490   event = anEvent->GetEventID();
00491
00492   std::vector<MollerDetectorHitsCollection*> THC;
00493
00494
00495   if(HCE) {
00496     for (int i=0; i<NUM_DETS; i++) {
00497       THC.push_back ((MollerDetectorHitsCollection*)(HCE->GetHC(hitsCollID[i])));
00498     }
00499   }
00500   G4int checkTrack1=0;
00501   G4int checkTrack2=0;
00502   //  G4cout<<"Checking for hits..."<<G4endl;
00503   for (int i=0; i<NUM_DETS; i++) {
00504     // somehow use: aHit->GetTrackID()==1 and aHit->GetTrackID()==2 with an indicator of first entry for that event/track?
00505     if(THC[i]){
00506       int n_hit = THC[i]->entries();
00507       /* // Just do first hit; rate ~65GHz - missing second electron?
00508   if (n_hit>0) {
00509   MollerDetectorHit* aHit = (*THC[i])[0];
00510   //Decide here what kind of data we want to keep
00511   if (aHit->GetType()==0) AddData(aHit);
00512   if (aHit->GetType()==4) AddData(aHit);
00513   }
00514   }
00515   }*/
00516       //  G4cout<<"Done checking for hits..."<<G4endl;
00517       checkTrack1=0; //need to reset for each detector...
00518       checkTrack2=0;
00519       if (n_hit>0) {
00520
00521   for(int i1=0;i1<n_hit;i1++) {
00522     MollerDetectorHit* aHit = (*THC[i])[i1];
00523     //aHit->Print();
00524     //aHit->Draw();
00525     //    G4cout<<"Ev "<<event<<", det: "<<i<<", hit: "<<i1<<", track: "<<aHit->GetTrackID()<<", check: "<<checkTrack1<<", "<<checkTrack2<<", "<<G4endl;
00526     //Try to get only the first hit, but for both primary electrons...
00527     //Really need to define an ntuple variable for the n_hit somehow...
00528     //and/or do this checking in the analysis scripts...
00529
00530     if ((aHit->GetTrackID()==1)&&(checkTrack1==0)) {
00531       if (aHit->GetType()==0) AddData(aHit);
00532       if (aHit->GetType()==4) AddData(aHit);
00533       checkTrack1++;
00534     } else if ((aHit->GetTrackID()==2)&&(checkTrack2==0)){
00535       if (aHit->GetType()==0) AddData(aHit);
00536       if (aHit->GetType()==4) AddData(aHit);
00537       checkTrack2++;
00538     }
00539
00540   }
00541
00542       }
00543     }
00544   }
00545
00546   gRootAnalysis->SetMomentum0(0,0,0,0);
00547   gRootAnalysis->SetMomentum1(0,0,0,0);
00548   gRootAnalysis->SetMomentum2(0,0,0,0);
00549   gRootAnalysis->SetProcess(0);
00550
00551 }

Here is the call graph for this function:

void MollerAnalysis::EndOfRunAction ( const G4Run *   )  [virtual]

Reimplemented from RootAnalysis.

Definition at line 555 of file MollerAnalysis.cc.

References RootAnalysis::hfile.

00556 {
00557   if (gSystem) gSystem->ProcessEvents();
00558
00559   hfile->Write();
00560   hfile->Close();
00561
00562 }

const MollerAnalysis & MollerAnalysis::operator= ( const MollerAnalysis &  right  )

Definition at line 151 of file MollerAnalysis.cc.

References creatorProcess, ev_num, index, kineE0, kineE1, kineE2, partType, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, splitProcess, theta0, theta1, theta2, verboseLevel, x0, y0, and z0.

00152 {
00153   if (gSystem) gSystem->ProcessEvents();
00154
00155   ev_num=right.ev_num;
00156   partType=right.partType;
00157   splitProcess=right.splitProcess;
00158   creatorProcess=right.creatorProcess;
00159   index=right.index;
00160
00161   //  for (int i=0; i<NUM_DETS; i++) {
00162   //    hitsCollID[i]=right.hitsCollID[i];
00163   //  }
00164
00165   verboseLevel=right.verboseLevel;
00166
00167   kineE0=right.kineE0;
00168   kineE1=right.kineE1;
00169   kineE2=right.kineE2;
00170
00171   px0=right.px0;
00172   py0=right.py0;
00173   pz0=right.pz0;
00174
00175   px1=right.px1;
00176   py1=right.py1;
00177   pz1=right.pz1;
00178
00179   px2=right.px2;
00180   py2=right.py2;
00181   pz2=right.pz2;
00182
00183   theta0=right.theta0;
00184   theta1=right.theta1;
00185   theta2=right.theta2;
00186
00187   x0=right.x0;
00188   y0=right.y0;
00189   z0=right.z0;
00190
00191   return *this;
00192
00193 }

void MollerAnalysis::SetDiffXS ( G4double  diffXS_in  )  [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 86 of file MollerAnalysis.hh.

References diffXS.

00086                                      {
00087     diffXS = diffXS_in;
00088   }

void MollerAnalysis::SetMomentum0 ( G4double  E0,
G4double  px,
G4double  py,
G4double  pz
) [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 64 of file MollerAnalysis.hh.

References kineE0, px0, py0, pz0, and theta0.

00064                                                                         {
00065     kineE0=E0;
00066     px0=px;
00067     py0=py;
00068     pz0=pz;
00069     theta0 = sqrt(px0*px0 + py0*py0);
00070   }

void MollerAnalysis::SetMomentum1 ( G4double  E1,
G4double  px,
G4double  py,
G4double  pz
) [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 71 of file MollerAnalysis.hh.

References kineE1, px1, py1, pz1, and theta1.

00071                                                                         {
00072     kineE1=E1;
00073     px1=px;
00074     py1=py;
00075     pz1=pz;
00076     theta1 = sqrt(px1*px1 + py1*py1);
00077   }

void MollerAnalysis::SetMomentum2 ( G4double  E2,
G4double  px,
G4double  py,
G4double  pz
) [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 78 of file MollerAnalysis.hh.

References kineE2, px2, py2, pz2, and theta2.

00078                                                                         {
00079     kineE2=E2;
00080     px2=px;
00081     py2=py;
00082     pz2=pz;
00083     theta2 = sqrt(px2*px2 + py2*py2);
00084   }

void MollerAnalysis::SetProcess ( G4int  i  )  [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 98 of file MollerAnalysis.hh.

References index.

00098                            {
00099     index=i;
00100   }

void MollerAnalysis::SetRate ( G4double  rate_in  )  [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 94 of file MollerAnalysis.hh.

References rate.

00094                                  {
00095     rate = rate_in;
00096   }

void MollerAnalysis::SetRootFileName ( const G4String &  nam  )

Definition at line 199 of file MollerAnalysis.cc.

References rootfileName.

Referenced by MollerAnalysisMessenger::SetNewValue().

00200 {
00201   rootfileName = nam;
00202 }

Here is the caller graph for this function:

void MollerAnalysis::SetTotXS ( G4double  totXS_in  )  [inline, virtual]

Reimplemented from RootAnalysis.

Definition at line 90 of file MollerAnalysis.hh.

References totXS.

00090                                    {
00091     totXS = totXS_in;
00092   }

void MollerAnalysis::UserSteppingAction ( const G4Step *  aStep  )  [virtual]

Get data that will go into ROOT tree

Reimplemented from RootAnalysis.

Definition at line 302 of file MollerAnalysis.cc.

References creatorProcess, kineE0, kineE1, kineE2, partType, px0, px1, px2, py0, py1, py2, pz0, pz1, pz2, splitProcess, theta0, theta1, theta2, x0, y0, and z0.

00303 {
00304   /** Get data that will go into ROOT tree **/
00305
00306   G4Track* fTrack = aStep->GetTrack();
00307
00308
00309   if (fTrack->GetTrackStatus()!=fAlive) {
00310  //   printf("track is not 'alive.'\n");
00311     return;
00312   }
00313
00314   G4int tracking = 1;
00315
00316   G4StepPoint* thePrePoint = aStep->GetPreStepPoint();
00317   G4StepPoint* thePostPoint = aStep->GetPostStepPoint();
00318   G4VPhysicalVolume* thePrePV = thePrePoint->GetPhysicalVolume();
00319   G4Material* material = fTrack->GetMaterial();
00320
00321   const G4VProcess* originProcess = fTrack->GetCreatorProcess();
00322   const G4VProcess* stepProcess = thePostPoint->GetProcessDefinedStep();
00323
00324   G4String process;
00325   if (originProcess!=0) process = originProcess->GetProcessName();
00326   G4String process1;
00327   if (stepProcess!=0) process1 = stepProcess->GetProcessName();
00328
00329
00330   G4String volume = fTrack->GetVolume()->GetName();
00331   G4String particle = fTrack->GetDefinition()->GetParticleName();
00332
00333
00334   if (process=="eIoni") creatorProcess=0;
00335   else if (process=="conv") creatorProcess=1;
00336   else if (process=="Decay") creatorProcess=2;
00337   else if (process=="annihil") creatorProcess=3;
00338   else if (process=="eBrem") creatorProcess=4;
00339   else if (process=="phot") creatorProcess=5;
00340   else if (process=="compt") creatorProcess=6;
00341   else if (process=="Transportation") creatorProcess=7;
00342   else if (process=="msc") creatorProcess=8;
00343   else creatorProcess=9;
00344
00345   //G4bool ion = process=="eIoni";
00346
00347   if ((particle == "e-")
00348       && (fTrack->GetVertexKineticEnergy()==11*GeV)
00349       && ((thePrePoint->GetKineticEnergy()-
00350      thePostPoint->GetKineticEnergy())>1.00*GeV)
00351       && (process1=="eIoni"))
00352     {
00353       if (kineE0==0 || kineE1==0) {
00354   kineE0 = thePrePoint->GetKineticEnergy();
00355   kineE1 = thePostPoint->GetKineticEnergy();
00356   px0 = thePrePoint->GetMomentumDirection().x();
00357   py0 = thePrePoint->GetMomentumDirection().y();
00358   pz0 = thePrePoint->GetMomentumDirection().z();
00359   px1 = thePostPoint->GetMomentumDirection().x();
00360   py1 = thePostPoint->GetMomentumDirection().y();
00361   pz1 = thePostPoint->GetMomentumDirection().z();
00362   theta0 = sqrt(px0*px0 + py0*py0);
00363   theta1 = sqrt(px1*px1 + py1*py1);
00364   x0 = thePostPoint->GetPosition().x();
00365   y0 = thePostPoint->GetPosition().y();
00366   z0 = thePostPoint->GetPosition().z();
00367       }
00368
00369       if (process1=="eIoni") splitProcess=0;
00370       else if (process1=="conv") splitProcess=1;
00371       else if (process1=="Decay") splitProcess=2;
00372       else if (process1=="annihil") splitProcess=3;
00373       else if (process1=="eBrem") splitProcess=4;
00374       else if (process1=="photo") splitProcess=5;
00375       else if (process1=="compton") splitProcess=6;
00376       else if (process1=="Transportation") splitProcess=7;
00377       else splitProcess=8;
00378     }
00379
00380   if (tracking) {
00381
00382     G4ThreeVector worldPos = fTrack->GetPosition();
00383     G4ThreeVector worldMomentum = fTrack->GetMomentumDirection();
00384     G4ThreeVector vertexMomentum = fTrack->GetVertexMomentumDirection();
00385
00386     G4double scat_ang = sqrt(vertexMomentum.x()*vertexMomentum.x() +
00387            vertexMomentum.y()*vertexMomentum.y());
00388
00389     /*    if (scat_ang<0.002 || scat_ang>0.020) {
00390       return;
00391       }*/
00392
00393     G4double kineE = fTrack->GetKineticEnergy();
00394     G4double kineE0 = fTrack->GetVertexKineticEnergy();
00395
00396     G4bool ion = (process=="eIoni");
00397
00398     if (particle=="e-") partType=0;
00399     else if (particle=="e+") partType=1;
00400     else if (particle=="proton") partType=2;
00401     else if (particle=="antiproton") partType=3;
00402     else if (particle=="gamma") partType=4;
00403     else partType=5;
00404     /*
00405     if (partType!=4) {
00406
00407       fntup[0] = (Float_t)ion;
00408       fntup[1] = (Float_t)worldPos.x();
00409       fntup[2] = (Float_t)worldPos.y();
00410       fntup[3] = (Float_t)worldPos.z();
00411       fntup[4] = 0;
00412       fntup[5] = 0;
00413       fntup[6] = 0;
00414       fntup[7] = (Float_t)kineE;
00415       fntup[8] = (Float_t)worldMomentum.x();
00416       fntup[9] = (Float_t)worldMomentum.y();
00417       fntup[10] = (Float_t)worldMomentum.z();
00418
00419       fntup[11] = (Float_t)kineE0;
00420       fntup[12] = (Float_t)px0;
00421       fntup[13] = (Float_t)py0;
00422       fntup[14] = (Float_t)pz0;
00423       fntup[15] = (Float_t)kineE1;
00424       fntup[16] = (Float_t)px1;
00425       fntup[17] = (Float_t)py1;
00426       fntup[18] = (Float_t)pz1;
00427
00428       fntup[19] = (Float_t)fTrack->GetVertexKineticEnergy();
00429       fntup[20] = (Float_t)fTrack->GetVertexMomentumDirection().x();
00430       fntup[21] = (Float_t)fTrack->GetVertexMomentumDirection().y();
00431       fntup[22] = (Float_t)fTrack->GetVertexMomentumDirection().z();
00432
00433       fntup[23] = (Float_t)partType;
00434       fntup[24] = (Float_t)atof(volume);
00435       fntup[25] = (Float_t)theta0;
00436       fntup[26] = (Float_t)theta1;
00437       fntup[27] = (Float_t)theta2;
00438       fntup[28] = (Float_t)ev_num;
00439       fntup[29] = (Float_t)ion;
00440       fntup[30] = (Float_t)ev_num;
00441
00442
00443       ntup->Fill(fntup);
00444     }
00445     */
00446   }
00447
00448   /* KILL particle if it hits a detector */
00449   /* made of tungsten! */
00450   /*
00451   //  if(thePrePV->GetName()=="1"||thePrePV->GetName()=="2"||
00452      thePrePV->GetName()=="3"||thePrePV->GetName()=="4"||
00453      thePrePV->GetName()=="5"||thePrePV->GetName()=="6"||
00454      thePrePV->GetName()=="7"||thePrePV->GetName()=="8"||
00455      thePrePV->GetName()=="9"||thePrePV->GetName()=="10"||
00456      thePrePV->GetName()=="11"||thePrePV->GetName()=="12"||
00457      thePrePV->GetName()=="13"||thePrePV->GetName()=="14"||
00458      thePrePV->GetName()=="15"||thePrePV->GetName()=="16"||thePrePV->GetName()=="17"
00459      ){
00460   */
00461   //    G4cout<<"Material = "<<material->GetName();
00462   if((material->GetName()=="Tungsten")||(material->GetName()=="Pb")||(material->GetName()=="Copper")){
00463     if (kineE2 == 0 && process=="eIoni") {
00464       kineE2 = fTrack->GetVertexKineticEnergy();
00465       px2 = fTrack->GetVertexMomentumDirection().x();
00466       py2 = fTrack->GetVertexMomentumDirection().y();
00467       pz2 = fTrack->GetVertexMomentumDirection().z();
00468       theta2 = sqrt(px2*px2 + py2*py2);
00469       x0 = fTrack->GetVertexPosition().x();
00470       y0 = fTrack->GetVertexPosition().y();
00471       z0 = fTrack->GetVertexPosition().z();
00472
00473     }
00474     //    G4cout<<" Stopping the track..."<<G4endl;
00475     //    fTrack->SetTrackStatus(fStopAndKill);
00476     fTrack->SetTrackStatus(fKillTrackAndSecondaries);
00477     return;
00478   }
00479   //  G4cout<<endl;
00480 }

Field Documentation

MollerAnalysisMessenger* MollerAnalysis::analysisMessenger [private]

Definition at line 197 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), and ~MollerAnalysis().

G4int MollerAnalysis::creatorProcess [private]

Definition at line 201 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), and UserSteppingAction().

G4double MollerAnalysis::diffXS [private]

Definition at line 236 of file MollerAnalysis.hh.

Referenced by AddData(), and SetDiffXS().

const G4bool MollerAnalysis::doCOLS = 0 [static, private]

Definition at line 188 of file MollerAnalysis.hh.

const G4bool MollerAnalysis::doDIPS = 0 [static, private]

Definition at line 187 of file MollerAnalysis.hh.

const G4bool MollerAnalysis::doQUADS = 0 [static, private]

Definition at line 189 of file MollerAnalysis.hh.

G4int MollerAnalysis::ev_num [private]

Definition at line 200 of file MollerAnalysis.hh.

Referenced by AddData(), BeginOfEventAction(), MollerAnalysis(), and operator=().

G4double MollerAnalysis::event [private]

Definition at line 210 of file MollerAnalysis.hh.

Referenced by AddData().

Float_t MollerAnalysis::fntup[39] [private]

Definition at line 204 of file MollerAnalysis.hh.

Referenced by AddData().

G4double MollerAnalysis::generator [private]

Definition at line 210 of file MollerAnalysis.hh.

std::vector<G4int> MollerAnalysis::hitsCollID [private]

Definition at line 206 of file MollerAnalysis.hh.

Referenced by BeginOfEventAction(), and EndOfEventAction().

G4int MollerAnalysis::index [private]

Definition at line 200 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), and SetProcess().

G4double MollerAnalysis::kineE0 [private]

Definition at line 212 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum0(), and UserSteppingAction().

G4double MollerAnalysis::kineE1 [private]

Definition at line 213 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum1(), and UserSteppingAction().

G4double MollerAnalysis::kineE2 [private]

Definition at line 214 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum2(), and UserSteppingAction().

MollerDetectorConstruction* MollerAnalysis::myDetector [private]

Definition at line 193 of file MollerAnalysis.hh.

Referenced by MollerAnalysis().

TNtuple* MollerAnalysis::ntup [private]

Definition at line 203 of file MollerAnalysis.hh.

Referenced by AddData(), and BeginOfRunAction().

G4int MollerAnalysis::NUM_DETS [private]

Definition at line 195 of file MollerAnalysis.hh.

Referenced by BeginOfEventAction(), EndOfEventAction(), and MollerAnalysis().

G4int MollerAnalysis::partType [private]

Definition at line 201 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), operator=(), and UserSteppingAction().

G4double MollerAnalysis::px0 [private]

Definition at line 216 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum0(), and UserSteppingAction().

G4double MollerAnalysis::px1 [private]

Definition at line 219 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum1(), and UserSteppingAction().

G4double MollerAnalysis::px2 [private]

Definition at line 222 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum2(), and UserSteppingAction().

G4double MollerAnalysis::py0 [private]

Definition at line 217 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum0(), and UserSteppingAction().

G4double MollerAnalysis::py1 [private]

Definition at line 220 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum1(), and UserSteppingAction().

G4double MollerAnalysis::py2 [private]

Definition at line 223 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum2(), and UserSteppingAction().

G4double MollerAnalysis::pz0 [private]

Definition at line 218 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum0(), and UserSteppingAction().

G4double MollerAnalysis::pz1 [private]

Definition at line 221 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum1(), and UserSteppingAction().

G4double MollerAnalysis::pz2 [private]

Definition at line 224 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum2(), and UserSteppingAction().

G4double MollerAnalysis::rate [private]

Definition at line 234 of file MollerAnalysis.hh.

Referenced by AddData(), and SetRate().

G4String MollerAnalysis::rootfileName [private]

Definition at line 198 of file MollerAnalysis.hh.

Referenced by BeginOfRunAction(), and SetRootFileName().

G4int MollerAnalysis::splitProcess [private]

Definition at line 201 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), and UserSteppingAction().

G4double MollerAnalysis::theta0 [private]

Definition at line 226 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum0(), and UserSteppingAction().

G4double MollerAnalysis::theta1 [private]

Definition at line 227 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum1(), and UserSteppingAction().

G4double MollerAnalysis::theta2 [private]

Definition at line 228 of file MollerAnalysis.hh.

Referenced by AddData(), MollerAnalysis(), operator=(), SetMomentum2(), and UserSteppingAction().

G4double MollerAnalysis::totXS [private]

Definition at line 235 of file MollerAnalysis.hh.

Referenced by AddData(), and SetTotXS().

G4int MollerAnalysis::verboseLevel [private]

Definition at line 208 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), and operator=().

G4double MollerAnalysis::x0 [private]

Definition at line 230 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), operator=(), and UserSteppingAction().

G4double MollerAnalysis::y0 [private]

Definition at line 231 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), operator=(), and UserSteppingAction().

G4double MollerAnalysis::z0 [private]

Definition at line 232 of file MollerAnalysis.hh.

Referenced by MollerAnalysis(), operator=(), and UserSteppingAction().

The documentation for this class was generated from the following files:
Generated on 16 Jun 2013 for mollersim by  doxygen 1.6.1
