MollerDetectorConstruction Class Reference

#include <MollerDetectorConstruction.hh>

Collaboration diagram for MollerDetectorConstruction:

[legend]

Public Member Functions
	MollerDetectorConstruction ()
virtual	~MollerDetectorConstruction ()
G4VPhysicalVolume *	Construct ()
void	CreateGlobalMagneticField ()
void	ReadGlobalMagneticField ()
void	ReadCollimatorGeometry (const char *filename)
void	WriteGeometryFile (const G4String &filename)
void	SetDetectorGeomFile (const G4String &)
void	SetReadGeo (G4bool value)
void	SetCollimGeomFile (const G4String &)
void	setTargetLength (G4double value)
void	setNumColl (G4int value)
G4int	getNumColl ()
Protected Member Functions
void	DefineQuadFields ()
void	DefineMaterials ()
Private Member Functions
G4VPhysicalVolume *	ConstructDetector ()
void	DumpGeometricalTree (G4VPhysicalVolume *aVolume, G4int depth=0)
Private Attributes
G4LogicalVolume *	mother_logic
std::vector< G4LogicalVolume * >	washer_logic
G4LogicalVolume *	target_logic
std::vector< G4LogicalVolume * >	trapeziod_logic
G4VPhysicalVolume *	worldVolume
G4VPhysicalVolume *	mother_phys
std::vector< G4VPhysicalVolume * >	washer_phys
G4VPhysicalVolume *	target_phys
std::vector< G4VPhysicalVolume * >	trapeziod_phys
G4VPhysicalVolume *	quartz_phys
G4Tubs *	target_solid
G4GDMLParser	fGDMLParser
G4Material *	Vacuum
G4Material *	Carbon
G4Material *	Al
G4Material *	Copper
G4Material *	Pb
G4Material *	Tungsten
G4Material *	Iron
G4Element *	H
G4Material *	LH2
MollerGlobalMagnetField *	pGlobalMagnetField
G4FieldManager *	fGlobalFieldManager
G4ChordFinder *	fGlobalChordFinder
G4Mag_UsualEqRhs *	fGlobalEquation
G4MagIntegratorStepper *	fGlobalStepper
G4double	fMinStep
MollerDetectorMessenger *	detectorMessenger
G4String	detfileName
G4String	collimfileName
G4double	fTargetLength
G4bool	fReadGeoFile
G4int	NUM_COLS
std::vector< G4double >	collInnerRadius
std::vector< G4double >	collOuterRadius
std::vector< G4double >	collUpstreamZ
std::vector< G4double >	collDownstreamZ
std::vector< G4String >	collMaterial

---

Detailed Description

Definition at line 27 of file MollerDetectorConstruction.hh.

---

Constructor & Destructor Documentation

MollerDetectorConstruction::MollerDetectorConstruction

(

)

Definition at line 53 of file MollerDetectorConstruction.cc.

References collimfileName, CreateGlobalMagneticField(), DefineMaterials(), detectorMessenger, fTargetLength, and NUM_COLS.

     :
     Vacuum(0), Carbon(0), Al(0), Copper(0), Pb(0), Tungsten(0),
     Iron(0), H(0), LH2(0),
     pGlobalMagnetField(0)
{

  //Set the magnetic field here
  CreateGlobalMagneticField();

  detectorMessenger = new MollerDetectorMessenger(this);
  DefineMaterials();
  fTargetLength  = 150.0*cm;
  collimfileName = "default_coll";
  NUM_COLS=10;

}

Here is the call graph for this function:

MollerDetectorConstruction::~MollerDetectorConstruction

(

)

[virtual]

Definition at line 71 of file MollerDetectorConstruction.cc.

References detectorMessenger, pGlobalMagnetField, trapeziod_logic, trapeziod_phys, washer_logic, and washer_phys.

{
  for (size_t i = 0; i < washer_logic.size(); i++)
    delete washer_logic[i];
  for (size_t i = 0; i < washer_phys.size(); i++)
    delete washer_phys[i];

  for (size_t i = 0; i < trapeziod_logic.size(); i++)
    delete trapeziod_logic[i];
  for (size_t i = 0; i < trapeziod_phys.size(); i++)
    delete trapeziod_phys[i];

  if (pGlobalMagnetField) delete pGlobalMagnetField;
  delete detectorMessenger;
}

---

Member Function Documentation

G4VPhysicalVolume * MollerDetectorConstruction::Construct

(

)

Definition at line 102 of file MollerDetectorConstruction.cc.

References ConstructDetector(), detfileName, DumpGeometricalTree(), fGDMLParser, fReadGeoFile, ReadGlobalMagneticField(), and worldVolume.

{

  G4cout << G4endl << "###### Calling MollerDetectorConstruction::Read() " << G4endl << G4endl;

  if (fReadGeoFile){

    fGDMLParser.SetOverlapCheck(false);
    fGDMLParser.Read(detfileName);

    worldVolume = fGDMLParser.GetWorldVolume();

  //==========================
  // List auxiliary info
  //==========================

  const G4GDMLAuxMapType* auxmap = fGDMLParser.GetAuxMap();

  G4cout << "Found " << auxmap->size()
         << " volume(s) with auxiliary information."
         << G4endl << G4endl;
  for(G4GDMLAuxMapType::const_iterator
      iter  = auxmap->begin();
      iter != auxmap->end(); iter++)
  {
    G4cout << "Volume " << ((*iter).first)->GetName()
           << " has the following list of auxiliary information: "<< G4endl;
    for (G4GDMLAuxListType::const_iterator
         vit  = (*iter).second.begin();
         vit != (*iter).second.end(); vit++)
    {
      G4cout << "--> Type: " << (*vit).type
             << " Value: "   << (*vit).value << std::endl;
    }
  }
  G4cout << G4endl<< G4endl;


  //==========================
  // Sensitive detectors
  //==========================
  G4SDManager* SDman = G4SDManager::GetSDMpointer();
  char detectorname[200];

  G4VSensitiveDetector* collimatordetector[100];

  G4int k=0;
  for(G4GDMLAuxMapType::const_iterator
      iter  = auxmap->begin();
      iter != auxmap->end(); iter++)
  {
    G4LogicalVolume* myvol = (*iter).first;
    G4cout << "Volume " << myvol->GetName();

    for (G4GDMLAuxListType::const_iterator
     vit  = (*iter).second.begin();
           vit != (*iter).second.end(); vit++)
    {
      if ((*vit).type == "SensDet")
      {
        G4String det_type = (*vit).value;
  //G4cout << " is a " << det_type <<  G4endl << G4endl;

  snprintf(detectorname,200,"/detector%i",k+1);
  collimatordetector[k] = new MollerDetectorSD(detectorname);

        if (collimatordetector[k] != 0)
        {

          G4cout << "  Creating sensitive detector " << det_type
                 << " for volume " << myvol->GetName()
                 <<  G4endl << G4endl;

          SDman->AddNewDetector(collimatordetector[k]);
          myvol->SetSensitiveDetector(collimatordetector[k]);
        }
        else
        {
          G4cout << det_type << " sensitive detector type not found" << G4endl;
  }
      }
    }
    k++;
  }

  //==========================
  // Visualization attributes
  //==========================

  G4VisAttributes* motherVisAtt= new G4VisAttributes(G4Colour(1.0,1.0,1.0));
  G4VisAttributes* daughterVisAtt= new G4VisAttributes(G4Colour(1.0,1.0,1.0));
  G4VisAttributes* targetVisAtt= new G4VisAttributes(G4Colour(1.0,1.0,0.0));
  G4VisAttributes* planeDetVisAtt= new G4VisAttributes(G4Colour(0.3,0.8,0.5));

  motherVisAtt->SetVisibility(false);

  targetVisAtt->SetVisibility(true);

  daughterVisAtt->SetVisibility(true);
  daughterVisAtt->SetForceWireframe (true);

  planeDetVisAtt->SetVisibility(true);
  planeDetVisAtt->SetForceWireframe (true);

  G4VisAttributes* WVisAtt= new G4VisAttributes(G4Colour(0.7,0.7,0.7));
  G4VisAttributes* PbVisAtt= new G4VisAttributes(G4Colour(0.6,0.7,0.8));
  G4VisAttributes* CuVisAtt= new G4VisAttributes(G4Colour(1.0,0.5,0.1));
  G4VisAttributes* SiVisAtt= new G4VisAttributes(G4Colour(0.4,0.4,0.0));

  WVisAtt->SetVisibility(true);
  PbVisAtt->SetVisibility(true);
  CuVisAtt->SetVisibility(true);
  SiVisAtt->SetVisibility(true);

  worldVolume->GetLogicalVolume()->SetVisAttributes(motherVisAtt);


  for(int i=0;i<worldVolume->GetLogicalVolume()->GetNoDaughters();i++)
  {

    worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(daughterVisAtt);

    for (int j=0;j<worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetNoDaughters();j++) {
      worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(daughterVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("VacuumDet")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(planeDetVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("Tungsten")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(WVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("Lead")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(PbVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("Copper")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(CuVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("SILICON")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(SiVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->GetMaterial()->GetName().compare("LiquidHydrogen")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetDaughter(j)->GetLogicalVolume()->SetVisAttributes(targetVisAtt);
    }

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("VacuumDet")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(planeDetVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("Tungsten")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(WVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("Lead")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(PbVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("Copper")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(CuVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("SILICON")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(SiVisAtt);

    if (worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->GetMaterial()->GetName().compare("LiquidHydrogen")==0)
           worldVolume->GetLogicalVolume()->GetDaughter(i)->GetLogicalVolume()->SetVisAttributes(targetVisAtt);

  }

  //target_logic->SetVisAttributes(targetVisAtt);

  // TODO


  //==========================
  // Output geometry tree
  //==========================

  G4cout << G4endl << "Element table: " << G4endl << G4endl;
  G4cout << *(G4Element::GetElementTable()) << G4endl;

  G4cout << G4endl << "Material table: " << G4endl << G4endl;
  G4cout << *(G4Material::GetMaterialTable()) << G4endl;

  G4cout << G4endl << "Geometry tree: " << G4endl << G4endl;
  DumpGeometricalTree(worldVolume);

  ReadGlobalMagneticField();

  } else {

    worldVolume = ConstructDetector();
  }

  G4cout << G4endl << "###### Leaving MollerDetectorConstruction::Read() " << G4endl << G4endl;

  return worldVolume;
}

Here is the call graph for this function:

G4VPhysicalVolume * MollerDetectorConstruction::ConstructDetector

(

)

[private]

Definition at line 382 of file MollerDetectorConstruction.cc.

References collDownstreamZ, collimfileName, collInnerRadius, collMaterial, collOuterRadius, collUpstreamZ, Copper, fTargetLength, LH2, mother_logic, mother_phys, NUM_COLS, Pb, pi, ReadCollimatorGeometry(), ReadGlobalMagneticField(), target_logic, target_phys, target_solid, trapeziod_logic, trapeziod_phys, Tungsten, Vacuum, washer_logic, and washer_phys.

Referenced by Construct().

{

  G4SDManager* SDman = G4SDManager::GetSDMpointer();
  G4String SDname;

  G4VisAttributes* VacVisAtt= new G4VisAttributes(G4Colour(0.3,0.8,0.5));
  G4VisAttributes* WVisAtt= new G4VisAttributes(G4Colour(0.7,0.7,0.7));
  G4VisAttributes* PbVisAtt= new G4VisAttributes(G4Colour(0.6,0.7,0.8));
  G4VisAttributes* CuVisAtt= new G4VisAttributes(G4Colour(1.0,0.5,0.1));

  VacVisAtt->SetVisibility(true);
  VacVisAtt->SetForceWireframe (true);

  WVisAtt->SetVisibility(true);
  PbVisAtt->SetVisibility(true);
  CuVisAtt->SetVisibility(true);

  //--------------------------------------------------------------//
  //-----------------------------VOLUMES--------------------------//
  //--------------------------------------------------------------//

  G4double inner_rad = 0.0*cm;
  G4double start_angle = 0.0*deg;
  G4double end_angle = 360.0*deg;
  G4double half_side_mom = 200.0*cm;
  G4double half_len_mom = 4000.0*cm;

  G4double outer_rad_targ = 4.0*cm;
  G4double half_len_targ = fTargetLength/2;

  G4cout<< "target half-length = "<<half_len_targ/cm<<G4endl;

  G4UserLimits* userLimits = new G4UserLimits(1.0*cm);

  //------World-----//

  G4Box* mother_solid = new G4Box("boxMother", half_side_mom, half_side_mom,
           half_len_mom);

  mother_logic = new G4LogicalVolume(mother_solid, Vacuum, "logicMother", 0);
  mother_logic->SetUserLimits(userLimits);

  mother_phys = new G4PVPlacement(0,G4ThreeVector(),
          mother_logic, "111",
          0, false, 0);


  //------Target-----//

  target_solid = new G4Tubs("tubeTarget", inner_rad, outer_rad_targ,
           half_len_targ, start_angle, end_angle);

  target_logic = new G4LogicalVolume(target_solid, LH2, "logicTarget");
  //target_logic = new G4LogicalVolume(target_solid, Vacuum, "logicTarget"); //for optics plots

  target_phys = new G4PVPlacement(0,G4ThreeVector(0, 0, 0),
          target_logic, "targ_0",
          mother_logic , false, 0);
  //Visualization Attributes
  //
  G4VisAttributes* motherVisAtt= new G4VisAttributes(G4Colour(1.0,1.0,1.0));
  motherVisAtt->SetVisibility(false);
  mother_logic->SetVisAttributes(motherVisAtt);

  G4VisAttributes* targetVisAtt= new G4VisAttributes(G4Colour(1.0,1.0,0.0));
  targetVisAtt->SetVisibility(true);
  target_logic->SetVisAttributes(targetVisAtt);


  //------Phi defining collimators
  const G4int numsectors=7;
  //  G4double startingphi=-pi/2;
  G4double startingphi=pi/2;
  G4double startingz=5.8*m;
  G4double radius=0.6*m;
  G4double internalholeradius=0*m;
  G4double thickness = 9.9*cm;

  G4VSensitiveDetector* collimatordetector[7];

  G4double openingangle=pi/numsectors;
  G4Trd* trapeziod_solid = new G4Trd("trapeziod_solid",
             radius*tan(openingangle/2.),0.,thickness,thickness,(radius-internalholeradius)/2.);
  G4RotationMatrix rotmatrix[numsectors];
  char trapphysname[100], traplogname[100];
  char washphysname[100];
  char detectorname[200];

  for (G4int sector = 1; sector <= numsectors; sector++) {
    G4double phi = startingphi + 2.*(sector-1)*(pi/numsectors);
    rotmatrix[sector-1].rotateX(pi/2.);
    rotmatrix[sector-1].rotateZ(-phi);
    G4double xpos = radius/2.*sin(phi);
    G4double ypos = radius/2.*cos(phi);

    snprintf(traplogname,100,"trapeziod_log_%i",sector);
    trapeziod_logic.push_back(new G4LogicalVolume(trapeziod_solid, Tungsten, traplogname));


    snprintf(trapphysname,100,"trap_phys_%i",sector+NUM_COLS);


    trapeziod_phys.push_back(
      new G4PVPlacement(G4Transform3D(rotmatrix[sector-1],
             G4ThreeVector(xpos,ypos,startingz)),
           //0,G4ThreeVector(xpos,ypos,startingz),
           trapeziod_logic.back(),
           trapphysname,
           mother_logic,
           false,
           0,
           false));
    snprintf(detectorname,200,"/detector%i",sector+NUM_COLS);
    collimatordetector[sector-1] = new MollerDetectorSD(SDname=detectorname);
    SDman->AddNewDetector(collimatordetector[sector-1]);
    trapeziod_logic.back()->SetSensitiveDetector(collimatordetector[sector-1]);
    trapeziod_logic.back()->SetVisAttributes(WVisAtt);


  }


  //-----3QC1B (center)-----//
  //-----Washers----//

  std::vector<G4VSensitiveDetector*> detector;

  // For E'=2.75 GeV, theta_lab=0.0167 rad which from z=0.75 m to z=5.9 m gives a radius of 11.1 cm.
  //For E'=8.25 GeV, theta_lab=0.00557 rad which from z=-0.75 m to z=5.9 m gives a radius of 5.15*tan(0.00557)= 2.86 cm

  //  G4double inrad[NUM_COLS], extrad[NUM_COLS], detzmin[NUM_COLS], detzmax[NUM_COLS],
  std::vector<G4double> dethalfleng;
  std::vector<G4double> loc;
  dethalfleng.resize(NUM_COLS);
  loc.resize(NUM_COLS);
  //  G4VSolid* washer_solid[NUM_COLS];

  std::vector<G4VSolid*> washer_solid;
  washer_solid.resize(NUM_COLS);

  char washer_logicname[100];

  //G4String collgeofile=("$G4WORKDIR/geometry/"+collimfileName+".dat");
  G4String gPath = ".";
  if (getenv("MOLLERGEANTDIR"))
    gPath = getenv("MOLLERGEANTDIR");
  else
    G4cout << "You do not have MOLLERGEANTDIR defined in your environment!" << G4endl;
  G4String collgeofile=(gPath+"/geometry/"+collimfileName+".dat");
  ReadCollimatorGeometry(collgeofile);

  for (int i=0; i<NUM_COLS; i++) {
    loc[i] = (collUpstreamZ[i]+collDownstreamZ[i])/2;
    dethalfleng[i] = (collDownstreamZ[i]-collUpstreamZ[i])/2;

    washer_solid[i] = new G4Cons("solWasher"+
         G4UIcommand::ConvertToString((i+1)),
         collInnerRadius[i], collOuterRadius[i],
         collInnerRadius[i], collOuterRadius[i], dethalfleng[i],
         start_angle, end_angle);

    snprintf(washer_logicname,100,"logicWasher_%i",i);
    snprintf(washphysname,100,"wash_phys_%i",i);

    SDname = "/detector";
    SDname+=G4UIcommand::ConvertToString((i+1));

    detector.push_back (new MollerDetectorSD(SDname));

    SDman->AddNewDetector(detector[i]);


    if (collMaterial[i] == "Vacuum") {
      washer_logic.push_back(new G4LogicalVolume(washer_solid[i], Vacuum, washer_logicname, 0));
      washer_logic.back()->SetSensitiveDetector(detector[i]);
      washer_logic.back()->SetVisAttributes(VacVisAtt);
    } else if (collMaterial[i] == "Tungsten") {
      washer_logic.push_back(new G4LogicalVolume(washer_solid[i], Tungsten, washer_logicname, 0));
      washer_logic.back()->SetSensitiveDetector(detector[i]);
      washer_logic.back()->SetVisAttributes(WVisAtt);
     } else if (collMaterial[i] == "Lead") {
      washer_logic.push_back(new G4LogicalVolume(washer_solid[i], Pb, washer_logicname, 0));
      washer_logic.back()->SetSensitiveDetector(detector[i]);
      washer_logic.back()->SetVisAttributes(PbVisAtt);
    } else if (collMaterial[i] == "Copper") {
      washer_logic.push_back(new G4LogicalVolume(washer_solid[i], Copper, washer_logicname, 0));
      washer_logic.back()->SetSensitiveDetector(detector[i]);
      washer_logic.back()->SetVisAttributes(CuVisAtt);
     } else {
      G4cerr << G4endl<< " Check collimator "<< i <<" -  material not specified!" << G4endl;
      break;
    }


    washer_phys.push_back(new G4PVPlacement(0,G4ThreeVector(0, 0, loc[i]),
               washer_logic.back(),
               washphysname,
               mother_logic, false, 0));

  }


  ReadGlobalMagneticField();

  return mother_phys;

}

Here is the call graph for this function:

Here is the caller graph for this function:

void MollerDetectorConstruction::CreateGlobalMagneticField

(

)

Definition at line 598 of file MollerDetectorConstruction.cc.

References fGlobalChordFinder, fGlobalEquation, fGlobalFieldManager, fGlobalStepper, and pGlobalMagnetField.

Referenced by MollerDetectorConstruction().

{

  //--------- Magnetic Field -------------------------------

  //============================================
  //  Define the global magnet field Manager
  //============================================
  pGlobalMagnetField = new MollerGlobalMagnetField();

  // Get transportation, field, and propagator  managers
  fGlobalFieldManager = G4TransportationManager::GetTransportationManager()->GetFieldManager();
  G4TransportationManager::GetTransportationManager()->GetPropagatorInField()->SetLargestAcceptableStep(25*cm);
  fGlobalFieldManager->SetDetectorField(pGlobalMagnetField);
  fGlobalEquation = new G4Mag_UsualEqRhs(pGlobalMagnetField);

  // taken from one of the Geant4 presentation:
  // - If the field is calculated from a field map, a lower order stepper
  //   is recommended: the less smooth the field is, the lower the order of the
  //   stepper that should be used. For very rough fields one should use 1st order
  //   stepper, for a somewhat smooth field one must choose between 1st and 2nd
  //   order stepper.

  //fGlobalStepper  = new G4ClassicalRK4(fGlobalEquation);  // classical 4th order stepper
  //fGlobalStepper  = new G4ExplicitEuler(fGlobalEquation); //           1st order stepper
  //fGlobalStepper  = new G4ImplicitEuler(fGlobalEquation); //           2nd order stepper
  fGlobalStepper  = new G4SimpleRunge(fGlobalEquation);   //           2nd order stepper


  // Provides a driver that talks to the Integrator Stepper, and insures that
  //   the error is within acceptable bounds.
  G4MagInt_Driver* fGlobalIntgrDriver = new G4MagInt_Driver(1.0e-3*mm,
                  fGlobalStepper,
                  fGlobalStepper->GetNumberOfVariables());

  fGlobalChordFinder = new G4ChordFinder(fGlobalIntgrDriver);



  //       G4bool fieldChangesEnergy = false;
  //       G4FieldManager* pFieldMgr = new G4FieldManager(myField,pChordFinder,FieldChangeEnergy);
  //       LocalLogicalVolume = new G4LogicalVolume(shape, material,"name",pFieldMgr,0,0);

  //   // minimal step of 1 mm is default
  //   fMinStep = 0.01*mm ;
  //
  //   fGlobalChordFinder = new G4ChordFinder (pGlobalMagnetField,
  //                                           fMinStep,
  //                                           fGlobalStepper);

  fGlobalFieldManager->SetChordFinder(fGlobalChordFinder);
}

Here is the caller graph for this function:

void MollerDetectorConstruction::DefineMaterials

(

)

[protected]

Definition at line 321 of file MollerDetectorConstruction.cc.

References Al, Carbon, Copper, H, Iron, LH2, Pb, Tungsten, and Vacuum.

Referenced by MollerDetectorConstruction().

{

  //--------------------------------------------------------------//
  //-----------------------------MATERIALS------------------------//
  //--------------------------------------------------------------//


  G4double a;
  G4double z;
  G4double density;
  G4double temp = 20.27*kelvin;
  G4int natoms;
  G4int nComponents;
  G4String symbol;

  //-----VACUUM------//

  Vacuum = new G4Material("Vacuum", z=1., a=1.01*g/mole,
        density= universe_mean_density,
        kStateGas, 2.73*kelvin, 3.e-18*pascal);

  //-----Carbon------//
  Carbon = new G4Material("Carbon", z= 6., a= 12.01*g/mole,
        density= 2.265*g/cm3);

  //-----Aluminum------//
  Al = new G4Material("Aluminum", z= 13., a= 26.98*g/mole,
          density= 2.7*g/cm3);

  //-----Copper------//
  Copper = new G4Material("Copper", z= 11., a= 63.54*g/mole,
        density= 8.96*g/cm3);

  //-----Lead------//
  Pb = new G4Material("Lead", z= 82., a= 207.19*g/mole,
          density= 11.35*g/cm3);

  //-----Tungsten----//
  Tungsten = new G4Material("Tungsten", z= 74., a= 183.85*g/mole,
          density= 19.3*g/cm3);

  //-----Iron-----//
  Iron = new G4Material("Iron", z= 26., a= 55.85*g/mole,
      density= 7.87*g/cm3);

  //-----Liquid Hydrogen---//
  H  = new G4Element("Hydrogen", symbol="H",
         z= 1., a= 1.00794*g/mole);
  LH2 = new G4Material("Liquid Hydrogen", density= 0.0708*g/cm3,
            nComponents=1, kStateLiquid, temp);

  LH2->AddElement(H, natoms=1);


  // Print materials defined.
  G4cout << G4endl << "The materials defined are : " << G4endl << G4endl;
  G4cout << *(G4Material::GetMaterialTable()) << G4endl;

}

Here is the caller graph for this function:

void MollerDetectorConstruction::DefineQuadFields

(

)

[protected]

void MollerDetectorConstruction::DumpGeometricalTree	(	G4VPhysicalVolume *	aVolume,
		G4int	depth = 0
	)			[private]

Definition at line 303 of file MollerDetectorConstruction.cc.

Referenced by Construct().

{
  for(int isp=0;isp<depth;isp++)
  { G4cout << "  "; }
  G4cout << aVolume->GetName() << "[" << aVolume->GetCopyNo() << "] "
         << aVolume->GetLogicalVolume()->GetName() << " "
         << aVolume->GetLogicalVolume()->GetNoDaughters() << " "
         << aVolume->GetLogicalVolume()->GetMaterial()->GetName();
  if(aVolume->GetLogicalVolume()->GetSensitiveDetector())
  {
    G4cout << " " << aVolume->GetLogicalVolume()->GetSensitiveDetector()
                            ->GetFullPathName();
  }
  G4cout << G4endl;
  for(int i=0;i<aVolume->GetLogicalVolume()->GetNoDaughters();i++)
  { DumpGeometricalTree(aVolume->GetLogicalVolume()->GetDaughter(i),depth+1); }
}

Here is the caller graph for this function:

G4int MollerDetectorConstruction::getNumColl

(

)

[inline]

Definition at line 54 of file MollerDetectorConstruction.hh.

References NUM_COLS.

Referenced by MollerAnalysis::MollerAnalysis().

{return NUM_COLS; };

Here is the caller graph for this function:

void MollerDetectorConstruction::ReadCollimatorGeometry

(

const char *

filename

)

Definition at line 650 of file MollerDetectorConstruction.cc.

References collDownstreamZ, collInnerRadius, collMaterial, collOuterRadius, collUpstreamZ, and NUM_COLS.

Referenced by ConstructDetector().

{

  G4cout << G4endl << "###### Calling MollerDetectorConstruction::ReadCollimatorGeometry " << G4endl << G4endl;
  //G4cout << G4endl;
  //G4cout << "------------------------------------------------" << G4endl;
  //G4cout << " Getting collimator geometry from " << filename   << G4endl;
  //G4cout << "------------------------------------------------" << G4endl;


  G4int   coll_index=0;
  G4double ri,ro,zu,zd;
  G4String collmat;

  // open the collimator geometry file
  std::ifstream inputfile;
  inputfile.open(filename); // Open the file for reading.
  G4cout << G4endl << filename << " opened for reading, ncolls =" <<NUM_COLS<< G4endl<< G4endl;

  for (G4int nlines=0;nlines<NUM_COLS;nlines++) {

    if (!inputfile.good()) break;

    inputfile >> ri  >> ro >> zu >> zd >> collmat;

    //printf("coll ri ro zu zd: %2i  %f %f %f %f %s\n",coll_index, ri, ro, zu, zd, collmat.c_str());

    collInnerRadius.push_back (ri*cm);
    collOuterRadius.push_back (ro*cm);
    collUpstreamZ.push_back (zu*cm);
    collDownstreamZ.push_back (zd*cm);
    collMaterial.push_back (collmat);

    printf("coll ri ro zu zd: %2i  %7.2f %7.2f %7.2f %7.2f \t %s\n",coll_index, collInnerRadius[nlines]/cm, collOuterRadius[nlines]/cm,
     collUpstreamZ[nlines]/cm, collDownstreamZ[nlines]/cm, collMaterial[nlines].c_str());
    //printf("coll ri ro zu zd: %2i  %f %f %f %f %s\n",coll_index, collInnerRadius[nlines], collOuterRadius[nlines],
    //   collUpstreamZ[nlines], collDownstreamZ[nlines], collMaterial[nlines]->GetName());
    coll_index++;
  }


  // close file
  inputfile.close();

  if (coll_index!=NUM_COLS) {
    G4cerr <<"coll_index, "<< coll_index<<" not equal to NUM_COLS,"<<NUM_COLS<<G4endl;
  }
  else if ((int)collDownstreamZ.size()!=NUM_COLS) {
    G4cerr <<"collDownstreamZ.size(), "<< collDownstreamZ.size()<<" not equal to NUM_COLS, "<<NUM_COLS<<G4endl;
  }
  G4cout << "... done reading " << coll_index << " lines." << G4endl;

  G4cout << G4endl << "###### Leaving MollerDetectorConstruction::ReadCollimatorGeometry " << G4endl << G4endl;
}

Here is the caller graph for this function:

void MollerDetectorConstruction::ReadGlobalMagneticField

(

)

Definition at line 592 of file MollerDetectorConstruction.cc.

References pGlobalMagnetField, and MollerGlobalMagnetField::ReadMagneticField().

Referenced by Construct(), and ConstructDetector().

{
  pGlobalMagnetField->ReadMagneticField();
}

Here is the call graph for this function:

Here is the caller graph for this function:

void MollerDetectorConstruction::SetCollimGeomFile

(

const G4String &

nam

)

Definition at line 87 of file MollerDetectorConstruction.cc.

References collimfileName.

Referenced by MollerDetectorMessenger::SetNewValue().

{
  collimfileName = nam;
}

Here is the caller graph for this function:

void MollerDetectorConstruction::SetDetectorGeomFile

(

const G4String &

nam

)

Definition at line 91 of file MollerDetectorConstruction.cc.

References detfileName.

Referenced by MollerDetectorMessenger::SetNewValue().

{
  G4String fPath = ".";
  if (getenv("MOLLERGEANTDIR"))
    fPath = getenv("MOLLERGEANTDIR");
  else
    G4cout << "You do not have MOLLERGEANTDIR defined in your environment!" << G4endl;

  detfileName = (fPath+"/"+nam);
}

Here is the caller graph for this function:

void MollerDetectorConstruction::setNumColl

(

G4int

value

)

[inline]

Definition at line 52 of file MollerDetectorConstruction.hh.

References NUM_COLS.

Referenced by MollerDetectorMessenger::SetNewValue().

{ NUM_COLS = value; G4cout<<G4endl<<G4endl<<"NUM_COLS (detcons) = "<<NUM_COLS<<G4endl<<G4endl;};

Here is the caller graph for this function:

void MollerDetectorConstruction::SetReadGeo

(

G4bool

value

)

[inline]

Definition at line 48 of file MollerDetectorConstruction.hh.

References fReadGeoFile.

Referenced by MollerDetectorMessenger::SetNewValue().

{fReadGeoFile  = value;};

Here is the caller graph for this function:

void MollerDetectorConstruction::setTargetLength

(

G4double

value

)

[inline]

Definition at line 50 of file MollerDetectorConstruction.hh.

References fTargetLength.

Referenced by MollerDetectorMessenger::SetNewValue().

{ fTargetLength = value; };

Here is the caller graph for this function:

void MollerDetectorConstruction::WriteGeometryFile

(

const G4String &

filename

)

Definition at line 296 of file MollerDetectorConstruction.cc.

References fGDMLParser, and mother_phys.

Referenced by MollerDetectorMessenger::SetNewValue().

{
  G4bool appendPointerAddress = true;
  // Note: only change to false if all names are unique
  fGDMLParser.Write(filename,mother_phys,appendPointerAddress);
}

Here is the caller graph for this function:

---

Field Documentation

G4Material* MollerDetectorConstruction::Al [private]

Definition at line 93 of file MollerDetectorConstruction.hh.

Referenced by DefineMaterials().

G4Material* MollerDetectorConstruction::Carbon [private]

Definition at line 92 of file MollerDetectorConstruction.hh.

Referenced by DefineMaterials().

std::vector<G4double> MollerDetectorConstruction::collDownstreamZ [private]

Definition at line 126 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ReadCollimatorGeometry().

G4String MollerDetectorConstruction::collimfileName [private]

Definition at line 117 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), MollerDetectorConstruction(), and SetCollimGeomFile().

std::vector<G4double> MollerDetectorConstruction::collInnerRadius [private]

Definition at line 123 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ReadCollimatorGeometry().

std::vector<G4String> MollerDetectorConstruction::collMaterial [private]

Definition at line 127 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ReadCollimatorGeometry().

std::vector<G4double> MollerDetectorConstruction::collOuterRadius [private]

Definition at line 124 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ReadCollimatorGeometry().

std::vector<G4double> MollerDetectorConstruction::collUpstreamZ [private]

Definition at line 125 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ReadCollimatorGeometry().

G4Material* MollerDetectorConstruction::Copper [private]

Definition at line 94 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and DefineMaterials().

MollerDetectorMessenger* MollerDetectorConstruction::detectorMessenger [private]

Definition at line 115 of file MollerDetectorConstruction.hh.

Referenced by MollerDetectorConstruction(), and ~MollerDetectorConstruction().

G4String MollerDetectorConstruction::detfileName [private]

Definition at line 116 of file MollerDetectorConstruction.hh.

Referenced by Construct(), and SetDetectorGeomFile().

G4GDMLParser MollerDetectorConstruction::fGDMLParser [private]

Definition at line 87 of file MollerDetectorConstruction.hh.

Referenced by Construct(), and WriteGeometryFile().

G4ChordFinder* MollerDetectorConstruction::fGlobalChordFinder [private]

Definition at line 108 of file MollerDetectorConstruction.hh.

Referenced by CreateGlobalMagneticField().

G4Mag_UsualEqRhs* MollerDetectorConstruction::fGlobalEquation [private]

Definition at line 109 of file MollerDetectorConstruction.hh.

Referenced by CreateGlobalMagneticField().

G4FieldManager* MollerDetectorConstruction::fGlobalFieldManager [private]

Definition at line 107 of file MollerDetectorConstruction.hh.

Referenced by CreateGlobalMagneticField().

G4MagIntegratorStepper* MollerDetectorConstruction::fGlobalStepper [private]

Definition at line 110 of file MollerDetectorConstruction.hh.

Referenced by CreateGlobalMagneticField().

G4double MollerDetectorConstruction::fMinStep [private]

Definition at line 112 of file MollerDetectorConstruction.hh.

G4bool MollerDetectorConstruction::fReadGeoFile [private]

Definition at line 119 of file MollerDetectorConstruction.hh.

Referenced by Construct(), and SetReadGeo().

G4double MollerDetectorConstruction::fTargetLength [private]

Definition at line 118 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), MollerDetectorConstruction(), and setTargetLength().

G4Element* MollerDetectorConstruction::H [private]

Definition at line 98 of file MollerDetectorConstruction.hh.

Referenced by DefineMaterials().

G4Material* MollerDetectorConstruction::Iron [private]

Definition at line 97 of file MollerDetectorConstruction.hh.

Referenced by DefineMaterials().

G4Material* MollerDetectorConstruction::LH2 [private]

Definition at line 99 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and DefineMaterials().

G4LogicalVolume* MollerDetectorConstruction::mother_logic [private]

Definition at line 65 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector().

G4VPhysicalVolume* MollerDetectorConstruction::mother_phys [private]

Definition at line 74 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and WriteGeometryFile().

G4int MollerDetectorConstruction::NUM_COLS [private]

Definition at line 121 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), getNumColl(), MollerDetectorConstruction(), ReadCollimatorGeometry(), and setNumColl().

G4Material* MollerDetectorConstruction::Pb [private]

Definition at line 95 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and DefineMaterials().

MollerGlobalMagnetField* MollerDetectorConstruction::pGlobalMagnetField [private]

Definition at line 105 of file MollerDetectorConstruction.hh.

Referenced by CreateGlobalMagneticField(), ReadGlobalMagneticField(), and ~MollerDetectorConstruction().

G4VPhysicalVolume* MollerDetectorConstruction::quartz_phys [private]

Definition at line 79 of file MollerDetectorConstruction.hh.

G4LogicalVolume* MollerDetectorConstruction::target_logic [private]

Definition at line 67 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector().

G4VPhysicalVolume* MollerDetectorConstruction::target_phys [private]

Definition at line 76 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector().

G4Tubs* MollerDetectorConstruction::target_solid [private]

Definition at line 81 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector().

std::vector<G4LogicalVolume*> MollerDetectorConstruction::trapeziod_logic [private]

Definition at line 68 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ~MollerDetectorConstruction().

std::vector<G4VPhysicalVolume*> MollerDetectorConstruction::trapeziod_phys [private]

Definition at line 77 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ~MollerDetectorConstruction().

G4Material* MollerDetectorConstruction::Tungsten [private]

Definition at line 96 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and DefineMaterials().

G4Material* MollerDetectorConstruction::Vacuum [private]

Definition at line 91 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and DefineMaterials().

std::vector<G4LogicalVolume*> MollerDetectorConstruction::washer_logic [private]

Definition at line 66 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ~MollerDetectorConstruction().

std::vector<G4VPhysicalVolume*> MollerDetectorConstruction::washer_phys [private]

Definition at line 75 of file MollerDetectorConstruction.hh.

Referenced by ConstructDetector(), and ~MollerDetectorConstruction().

G4VPhysicalVolume* MollerDetectorConstruction::worldVolume [private]

Definition at line 72 of file MollerDetectorConstruction.hh.

Referenced by Construct().

---

The documentation for this class was generated from the following files:

• MollerDetectorConstruction.hh
• MollerDetectorConstruction.cc
